Sports Tile Corner Piece

Original price was: R20,00.Current price is: R19,00.

198 in stock

Our website is fully secured with SSL encryption.
Your payments are safe and protected.

198 in stock

Sports Tile Corner Piece – 107 × 107 × 14 mm for Modular Sports Flooring Edges

Sports Tile Corner Piece is a snap-fit perimeter accessory designed to finish compatible modular sports tile systems where straight ramp edging changes direction at a 90-degree corner. Available in inside 90° and outside 90° configurations, these corner pieces help create a cleaner, more complete perimeter around courts, activity zones, school halls, recreation areas and temporary event floors.

Sports Tile Corner Pieces are especially useful where a flooring layout contains:

  • External court corners.
  • Internal perimeter turns.
  • Doorway transitions.
  • Ramp runs that change direction.
  • Equipment access points.
  • Temporary event layouts.
  • School and club activity zones.

The corner piece is not the main flooring tile. It is a finishing accessory that works together with compatible sports tiles and ramp edging to complete the perimeter.

Sports Tile Corner Piece Technical Specifications

Specification Product Details
Product Name Sports Tile Corner Piece
Colour Black
Material polypropylene (PP)
Compatibility Compatible Sports Tiles and Ramp Edging
Installation Clip-On / Snap-Fit
Recommended Base Hard, Stable
Recommended Environment Indoor

What Is a Sports Tile Corner Piece?

A Sports Tile Corner Piece is used where modular ramp edging reaches a corner and needs to change direction.

Straight ramp edging works along linear sections of the sports tile perimeter. At a 90-degree turn, a dedicated corner piece provides a more appropriate connection than trying to force straight edging around the turn.

The result is a cleaner modular perimeter that follows the actual shape of the installed sports floor.

Corner pieces can be used for both:

  • External corners.
  • Internal corners.

The correct version should be selected according to the direction of the perimeter.

Inside vs Outside Sports Tile Corners

Understanding the difference between inside and outside corners is important before ordering.

Inside 90° Corner Piece

An inside corner is used where two perimeter runs meet around an inward-facing 90-degree turn.

This may occur where the flooring follows:

  • A recessed section.
  • A wall return.
  • An internal doorway configuration.
  • A shaped activity zone.

Outside 90° Corner Piece

An outside corner is used where the sports floor itself creates an external 90-degree corner.

This is common around:

  • Freestanding courts.
  • Rectangular activity areas.
  • Event floors.
  • Modular training zones.

Choosing the correct corner type helps maintain the intended ramp direction and connection system.

Why Use Sports Tile Corner Pieces?

A modular sports floor may have a number of exposed perimeter turns.

Without the appropriate corner component, installers may be tempted to cut or overlap straight ramp edging in ways that create an uneven or unfinished result.

Using compatible corner pieces helps create:

  • Cleaner 90-degree turns.
  • Better alignment between ramp sections.
  • A more complete perimeter appearance.
  • Replaceable corner components.
  • More consistent modular connections.
  • Easier future maintenance.

This is particularly useful for larger sports flooring installations where appearance and repeatable fitment matter.

Snap-Fit Sports Flooring Accessory

The corner piece uses a snap-fit connection.

This allows it to connect mechanically to compatible ramp edging and sports tile components without requiring adhesive in most standard installations.

Benefits of a snap-fit accessory system include:

  • Faster assembly.
  • Individual component replacement.
  • Easier layout changes.
  • Reduced dependence on permanent fixing.
  • Better integration with modular flooring.

The connectors should be properly aligned before pressure is applied.

Forcing an incompatible corner into a different tile or ramp system may damage the connectors.

Compatibility Must Be Confirmed

This is one of the most important points on the product page.

A corner piece should not be assumed to fit every 14 mm modular sports tile.

Compatibility depends on:

  • Connector shape.
  • Locking direction.
  • Ramp profile.
  • Tile edge design.
  • Product family.

A matching height alone does not guarantee compatibility.

Customers should confirm the exact sports tile and ramp edging system before ordering corner pieces.

Sports Court Corner Edging

Sports courts are one of the main applications for these components.

Where a modular sports floor has ramp edging around the perimeter, the corners require a suitable finishing accessory.

Potential applications include:

  • Basketball layouts.
  • Netball activity areas.
  • Volleyball courts.
  • Multipurpose sports surfaces.
  • School recreation zones.

For formal competition use, the complete sports flooring system should still be assessed according to the requirements of the relevant sporting organisation.

Corner Pieces for School Sports Flooring

Schools often use modular flooring because it can be installed over suitable existing surfaces and adjusted as facilities change.

Sports Tile Corner Pieces can help finish the perimeter around:

  • School halls.
  • Activity zones.
  • Covered courts.
  • Recreation spaces.
  • Multipurpose floors.

Because the corner pieces are modular, individual sections may be replaced if they become damaged.

Doorway Ramp Corners

Doorways can create more complex perimeter layouts than straight sidelines.

Where ramp edging approaches an entrance and changes direction, a compatible corner piece can help create a neater connection.

Before installation, consider:

  • Door clearance.
  • Threshold position.
  • Surrounding floor level.
  • Direction of pedestrian movement.
  • Available ramp space.

The correct corner orientation should be chosen before the ramp sections are cut.

Equipment Access Areas

Some sports and recreation spaces use equipment trolleys, storage carts or similar items around the flooring perimeter.

Corner pieces can help provide a more complete ramped boundary at turns where the modular flooring meets the surrounding surface.

However, no accessibility or wheel-load certification has been supplied.

The product should therefore not automatically be promoted as:

  • Wheelchair compliant.
  • Accessibility certified.
  • Suitable for all trolley loads.

Those applications depend on the complete installation and relevant site requirements.

Temporary Event Flooring

Modular sports flooring is useful for temporary events because individual components can be assembled and removed as required.

Snap-fit corner pieces support this type of installation because they can form part of a reusable perimeter system.

Potential temporary applications include:

  • Exhibition activity areas.
  • Pop-up sports zones.
  • School events.
  • Recreational events.
  • Temporary courts.

When the floor is dismantled, corner components should be stored carefully to protect the connectors.

Colour-Matched Corner Options

The original product information states that colour-match options may be available.

This can help the corner pieces coordinate with:

  • Court colours.
  • Ramp edging.
  • Activity-zone colours.
  • Facility branding.

Colour availability should be confirmed before ordering because not every colour may be stocked at all times.

Installing Sports Tile Corner Pieces

Before installation, make sure the main sports tile layout and straight ramp sections are correctly positioned.

Plan the Corner

Determine whether the location requires:

  • An inside 90° corner.
  • An outside 90° corner.

Dry-Fit the Ramp Sections

Place the adjoining straight ramp sections near the corner to check alignment.

Position the Corner Piece

Align the corner connectors with the compatible ramp and sports tile system.

Snap the Piece Into Position

Apply controlled pressure until the connectors are properly seated.

Fit the Adjacent Ramp Sections

Connect the straight edging to the corner piece.

Trim Where Necessary

If a ramp section is too long, trim the adjoining straight piece rather than altering the corner unnecessarily.

Check the Final Fit

Confirm that:

  • Connections are fully seated.
  • The corner lies correctly.
  • No sharp cut edges remain.
  • The surrounding perimeter remains aligned.

Can Straight Ramp Edging Be Trimmed?

Yes, the supplied installation information indicates that adjacent ramp pieces may be trimmed to length where required.

Before trimming:

  • Measure carefully.
  • Confirm the correct corner location.
  • Mark a straight cut line.
  • Avoid removing essential locking points.

After cutting, rough edges should be finished appropriately.

The corner piece itself should only be modified if absolutely necessary because altering it may affect its connection geometry.

Hard and Level Base Requirement

The complete modular sports floor should be installed over a suitable supporting base.

The supplied specification recommends a:

hard and level surface

A reasonably stable base helps the tile, ramp and corner components remain correctly aligned.

The corner accessory should not be expected to compensate for:

  • Broken concrete.
  • Severe floor level differences.
  • Loose substrates.
  • Large gaps.
  • Unstable surfaces.

Base problems should be corrected before the flooring system is installed.

Indoor and Covered Use

The supplied recommendation is:

indoor and covered outdoor use

This may include:

  • Sports halls.
  • School facilities.
  • Covered courts.
  • Recreation centres.
  • Covered event spaces.

No specific UV-stability or fully exposed weather-performance data has been supplied for the corner piece.

It should therefore not automatically be described as fully weatherproof or suitable for permanent exposed outdoor installation.

Sports Tile Corner Pieces and Perimeter Transitions

The corner piece forms part of the overall perimeter transition.

Its role is to connect compatible ramp sections at directional changes.

It does not independently determine whether a floor meets:

  • Accessibility requirements.
  • Trip-reduction standards.
  • Building regulations.
  • Wheelchair-access standards.

Those considerations depend on the complete flooring system, ramp geometry and site conditions.

Replaceable Modular Components

One advantage of snap-fit sports flooring is the ability to replace individual compatible components.

If one corner piece becomes:

  • Damaged.
  • Cracked.
  • Heavily scuffed.
  • Unable to connect correctly.

it may be replaced without removing the complete perimeter.

This can simplify maintenance in schools, sports clubs and busy recreation facilities.

Keeping several spare corner components can be useful for larger installations.

Cleaning Sports Tile Corner Pieces

Corners can collect dust and grit because debris often gathers around changes in floor direction.

Routine cleaning may include:

  • Sweeping.
  • Vacuuming.
  • Damp wiping.
  • Mild detergent.

Avoid aggressive solvents or highly abrasive cleaning tools unless material compatibility has been confirmed.

Checking Corner Connections

Corner connectors should be inspected periodically.

Pay particular attention in:

  • Busy entrances.
  • Equipment routes.
  • Court access points.
  • High-traffic event areas.

If a piece becomes partially disconnected, it should be reseated correctly.

A damaged component should be replaced rather than repeatedly forced back into position.

Planning a Complete Sports Tile Perimeter

Before ordering accessories, sketch or measure the full exposed perimeter.

Identify:

  • Straight sides.
  • External corners.
  • Internal corners.
  • Doorways.
  • Areas against permanent walls.

From this, calculate:

  • Number of straight ramp sections.
  • Number of outside corners.
  • Number of inside corners.

This approach is more reliable than ordering edging first and trying to solve the corners during installation.

Frequently Asked Questions About Sports Tile Corner Pieces

What is a Sports Tile Corner Piece used for?

  • It is used to connect compatible ramp edging at 90-degree turns around a modular sports flooring perimeter. It helps create a cleaner and more complete transition where straight edging changes direction.

What is the difference between inside and outside corners?

  • An inside corner is used around an inward-facing 90-degree turn, while an outside corner is used on the external corner of the modular flooring perimeter.

Can ramp pieces be trimmed next to the corner?

  • Yes. Adjacent straight ramp sections can be trimmed where necessary to create the required final length. Care should be taken not to remove important connection points.

Is the corner piece suitable for basketball courts?

It can be used with compatible modular flooring systems used for basketball and other sports. Compatibility with the actual tile system must still be confirmed.

Can it be used at doorways?

  • Yes, where compatible ramp edging changes direction around an entrance or transition. Door clearance and surrounding floor levels should be checked before installation.

Is it wheelchair compliant?

  •  The corner piece forms part of a ramped perimeter system, but compliance depends on the full transition design and relevant building requirements.

Can individual corner pieces be replaced?

  • Yes. Compatible snap-fit corner pieces can generally be replaced individually without removing the entire perimeter system.

Can the product be used outdoors?

  • The recommendation is for indoor and covered outdoor applications. Fully exposed outdoor suitability should be confirmed separately if long-term weather exposure is expected.

How should Sports Tile Corner Pieces be cleaned?

  • Sweep or vacuum accumulated grit and wipe with water and mild detergent when necessary. Avoid harsh solvents or abrasive cleaning methods.

Buy Sports Tile Corner Pieces

Choose Sports Tile Corner Pieces when you need to complete 90-degree turns around a compatible modular sports tile installation.

With inside and outside corner options,  these pieces integrate with compatible sports tile ramp edging to create a cleaner perimeter around courts, activity areas, entrances and temporary flooring layouts.

Before ordering, confirm the sports tile system, ramp profile and number of inside and outside corners required for the installation.

Additional information

Weight 0,07 kg
Dimensions 110 × 110 × 14 mm
Applications

Sports

Colour

Black

Dimension

107 × 107 × 14 mm

Durability

High Impact Resistant

Reviews

There are no reviews yet.

Be the first to review “Sports Tile Corner Piece”

Your email address will not be published. Required fields are marked *

0
0
Your Cart
Your cart is emptyReturn to Shop
Chat with Us
WhatsApp Icon
